PCS250
Features
Compact, sleek design
Untitled
Report via GSM (CID, SIA)
Instant notification of panel supervision loss
Arm or disarm the system via text message (SMS) to the PCS250
Reports alarms via text messages to up to 16 cellular phone numbers
Supports 2 cellular provider SIM cards for provider redundancy
Send pre-recorded voice messages to up to 8 telephone numbers to report alarms using the optional VDMP3 Paradox Plug-in Voice Module (GSM mode)
Reports events to the IPR512 GPRS / IP Monitoring Receiver and / or the IPRS-7 PC Receiver Software
Simple installation with 4-wire serial connection
Push notification to Insite GOLD app
Messages are secured with 256-bit (AES) encryption
Tamper switch support
Optional rod antenna can be installed up to 18m (60 ft) from the module using optional antenna cable extensions depending on the local signal strength
Increase the distance between the panel and the PCS250 module with an RS485 link (GSM mode only via e-bus). A CVT485 module must be added to the panel in order to accomplish this.
Compatible with EVO Series, Spectra SP Series, MG5000 and MG5050
Power Class | Class 4 (2W at 850 / 900 MHz) Class 2 (1W at 1800 / 1900 MHz) |
Antenna Bandwidth | 70 / 80 / 140 / 170 MHz |
Antenna Gain | <3 dBi; impedance 50 ohm <2W peak power |
Voltage Input | 12 Vdc nominal |
Current Consumption | 100 mA standby, average 450 mA (1.2A peak) during GPRS / GSM transmission |
Encryption | 128-bit (MD5 and RC4) and 256-bit (AES) |
SMS Protocol | 8-bit (IRA: ITU-T. 50) or 16-bit (UCS2 ISO / IEC10646) |
Humidity | 5 to 90% |
Operating Temperature | 0 to 50 °C (32 o 122 °F) |
Dimensions / Weight | 17.2 x 9.8 x 4.4 cm (6.8 x 3.9 x 1.7 in.) / 200g (7.05 oz) |
Report via GSM (CID, SIA)
Instant notification of panel supervision loss
Arm or disarm the system via text message (SMS) to the PCS250
Reports alarms via text messages to up to 16 cellular phone numbers
Supports 2 cellular provider SIM cards for provider redundancy
Send pre-recorded voice messages to up to 8 telephone numbers to report alarms using the optional VDMP3 Paradox Plug-in Voice Module (GSM mode)
Reports events to the IPR512 GPRS / IP Monitoring Receiver and / or the IPRS-7 PC Receiver Software
Simple installation with 4-wire serial connection
Push notification to Insite GOLD app
Messages are secured with 256-bit (AES) encryption
Tamper switch support
Optional rod antenna can be installed up to 18m (60 ft) from the module using optional antenna cable extensions depending on the local signal strength
Increase the distance between the panel and the PCS250 module with an RS485 link (GSM mode only via e-bus). A CVT485 module must be added to the panel in order to accomplish this.
Compatible with EVO Series, Spectra SP Series, MG5000 and MG5050
Certificate:
CE
EN 50131
EN 50130-5
EN 50136
EN 17065
