DCT2

Features
One high-sensitivity reed switch (magnet included)
Untitled

Power

1 x 3V lithium battery (DL2450)

RF Frequency

433 or 868 MHz

Battery Life

Between 1 and 5 years

Wireless Range

In a typical residential environment:

20m (65 ft) with MG6250;

40m (130 ft) with MG5000 / MG5050 / RTX3

Operating Temperature

0 to 50 °C (32 to 122 °F)

Dimensions

4.3 x 3 x 1.8 cm (1.7 x 1.2 x 0.7 in.)




Built-in strip antenna (printed)
Anti-tamper switch
Compatible with EVO Series (requires RTX3), Spectra SP Series (requires RX1), and Magellan Series
Certificate:
CE cUL/cETL UL/ETL FCC IC RCM R-NZ
